Product details of the shredder machine factory

Product Overview

SHIJIAZHUANG HUATAO IMPORT AND EXPORT TRADE CO.,LTD. insists on adopting superior raw material to produce first-class shredder machine factory. The product is tested on numerous quality parameters before supplying to patrons HUATAO Machine's shredder machine factory can play an important role in various fields. The product, with many good characteristics, is applicable to various fields.

Product Description

Compared with other similar products, our shredder machine factory has more advantages, specifically in the following aspects.

Product Introduction

Our four-axis shredder consists of four sets of shear rollers,which use different tool structures to cooperate with each other. After the material enters the shredding box, it is shredded into small pieces by the tearing and shearing action of the blades on the four sets of rollers. The four-axis shredder provides greater shear force , and can handle various tough and ductile waste materials and obtain consistent shapes and sizes.Since the upper blades can assist in crushing and grabbing materials, the materials are easier to enter the blade box, and no additional material pressing mechanism is required. It comes with a screen that can be screened and quickly replaced, and the material size can be adjusted according to the screen aperture. It can be said to be powerful and widely used.

未标题-1 (2)

Product Parameters

Model no	HT9080
Motor power	200kw
Blade thickness	25mm
Blade diameter	φ290
Blade quantity	32 Pieces
Spindle speed	16-25 r/min
Output height	985mm
Mesh aperture	φ40
Shredding size	900*800mm
Main body material	Carbon steel
Logo & color	Customized

未标题-3

Application Materials

Waste household appliances,domestic garbage,Industrial waste,hazardous waste,Waste plastics, metal waste, electronic waste, straw, waste furniture, paper mill ropes, wet garbage, waste batteries, fruit and vegetable waste, leather scraps, waste barrels, dry garbage, scrapped cars etc.

Advantages

Four-shaft blade structure

Unique four-shaft blade structure and blade tooth shape, the two sets of blade rollers at the bottom are responsible for the main crushing, and the two sets of blade rollers at the top are responsible for auxiliary crushing and grabbing, reducing invalid grabbing, reversal and idling time, and high efficiency.

High-performance blade

The raw materials of our blades are made of imported alloy steel, which has high wear resistance, moderate toughness, strong interchangeability and long service life.

International brand bearings

The quality of brand bearings is guaranteed and has high impact load resistance; the four-layer seal properly protects the bearings from sewage, sludge and dust interference, making the bearings last longer.

Intelligent monitoring system

The intelligent monitoring system includes one-button start and stop, status monitoring, data analysis, collaborative optimization, fault diagnosis, alarm linkage and other functions to help customers accurately control the operation status of the equipment in real time.

GI intelligent system

The intelligent monitoring system realizes intelligent data analysis, visualization of production process, timely abnormal alarm, safe and intelligent.

Optional drive system

According to project needs, motor drive or hydraulic drive system can be provided, among which the hydraulic drive system includes hydraulic motor, hydraulic pump, cooling device and necessary auxiliary devices. The entire power system is designed with low speed, high torque and strong crushing ability.

Heat treatment process

The proper use of heat treatment process makes the comprehensive performance of the knife box better and not easy to deform after long-term use; it significantly improves the mechanical properties of the parts and greatly extends their service life, so that one can replace multiple.

Economic benefits

The recycling process can create jobs and bring benefits to the local economy.

How to participate

Consumers can put cans in special recycling bins or hand them over to local recycling centers.

Sorting and processing

Recycled cans can be sorted, cleaned and smelted to be made into new aluminum products

Application

细节图 (2) (2)

细节图 (1)~2

细节图 (1) (2)

磁选机 (2)

磁选机 (1)

Company Introduction

Situated in SHIJIAZHUANG HUATAO IMPORT AND EXPORT TRADE CO.,LTD. is a modern enterprise. We mainly manage the business of E waste recycling line，medical waste recycling line，RDF/SRF line，Texitle recycling line,Waste Recycling Machine， Shredder Machine，Crusher Machine Waste Recycling Machine Spare Parts. Our company has a professional customer service team. The service team is capable of providing one-to-one service for customers, so we can solve customers' problems efficiently. You are always welcomed for inquiry.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
